HCZ系列化工流程泵 / HCZ Series

HCZ系列耐腐蚀化工流程泵性能参数表(4)
发布时间:2019-10-26 浏览次数：1617


规格
性能参数
配用电机（按照介质比重）
汽蚀余量
m req
进口法兰直径

转速

r/min

叶轮型式

流量

(m3/h)

扬程

(m)

效率

%

轴功率

kw

γ=1.0
γ=1.35
γ=1.84
65-250
1450
A
54
21
67
4.61
Y132S-4/5.5
Y132M-4/7.5
Y160M-4/11
0.9
100
B
50
20
67
4.06
Y132S-4/5.5
Y132M-4/7.5
Y160M-4/11
C
46
16
67
2.99
Y100L2-4/3
Y132S-4/5.5
Y132M-4/7.5
D
40
10
67
1.63
Y90L-4/2.2
Y100L-4/3
Y112M-4/4
2900
A
115
85
71
37.48
Y225M-2/45
Y250M-2/55
Y280S-2/75
3.4
100
B
115
75
71
33.07
Y200L2-2/37
Y225M-2/45
Y280S-2/75
C
100
65
71
24.92
Y200L1-2/30
Y200L2-2/37
Y250M-2/55
D
80
50
71
15.34
Y160L-2/18.5
Y180M-2/22
Y200L-2/30
65-315
1450
A
64
32
62
8.99
Y160M-4/11
Y160L-4/15
Y180M-4/18.5
1.3
100
B
61
30
62
8.03
Y160M-4/11
Y160M-4/11
Y160M-4/15
C
56
28
62
6.88
Y132M-4/7.5
Y160M-4/11
Y160L-4/15
D
54
24
62
5.69
Y132M-4/7.5
Y160M-4/11
Y160M-4/11
E
50
20
62
4.39
Y132S-4/5.5
Y132M-4/7.5
Y160M-4/11
F
42
6
62
2.95
Y112M-4/4
Y132S-4/5.5
Y132M-4/7.5
2900
A
135
135
66
75.17
Y280M-2/90
Y315S-2/110
Y315M2-2/160
3.6
100
B
130
125
66
67.03
Y280S-2/75
Y280M-2/90
Y315M1-2/132
C
115
115
66
54.55
Y250M-2/55
Y280S-2/75
Y315S-2/110
D
110
110
66
49.9
Y250M-2/55
Y280S-2/75
Y315S-2/110
E
90
85
66
31.55
Y200L2-2/37
Y225M-2/45
Y250M-2/55
F
75
70
66
21.65
Y180M-2/22
Y200L1-2/30
Y225M-2/45
80-160
1450
A
75
8
70
2.331.91
Y100L2-4/3
Y112M-4/4
Y132S-4/5.5
2.2
125
B
70
7
70
1.91
Y100L1-4/2.2
Y100L2-4/3
Y112M-4/4
C
70
5
70
1.36
Y190L-4/1.5
Y100L1-4/2.2
Y100L2-4/3
D
65
4
70
1.01
Y90S-4/1.1
Y90L-4/1.5
Y100L1-4/2.2
2900
A
170
30
76
18.27
Y180M-2/22
Y200L1-2/30
Y200L2-2/37
2.5
125
B
160
26
76
14.9
Y160-2/18.5
Y180M-2/22
Y200L1-2/30
C
150
22
76
11.82
Y160M2-2/15
Y160L-2/18.5
Y180M-2/22
D
130
16
76
7.45
Y160M1-2/11
Y160M1-2/11
Y160M2-2/15
80-200
1450
A
80
12
73
3.58
Y112M-4/4
Y132S-4/5.5
Y132M-4/7.5
1.9
125
B
75
11
73
3.08
Y112M-4/4
Y132S-4/5.5
Y132M-4/7.5
C
65
9
73
2.18
Y100L2-4/3
Y100L2-4/3
Y112M-4/4
D
60
6
73
1.34
Y90L-4/1.5
Y100L2-4/3
Y112M-4/4
2900
A
150
50
79
25.84
Y200L1-2/30
Y200L2-2/37
Y250M-2/55
3.8
125
B
140
46
79
22.19
Y200L1-2/30
Y200L2-2/37
Y225M-2/45
C
130
38
79
17.02
Y160L-2/18.5
Y200L1-2/30
Y200L2-2/37
D
110
26
79
9.86
Y160M1-2/11
Y160M-2/15
Y180M-2/18.5
80-250
1450
A
95
20
78
6.63
Y132M-4/7.5
Y160M-4/11
Y160L-4/15
1.3
125
B
90
19
78
5.97
Y132M-4/7.5
Y160M-4/11
Y160M-4/11
C
85
17
78
5.04
Y132S-4/5.5
Y132M-4/7.5
Y160M-4/11
D
75
14
78
3.66
Y132S-4/5.5
Y132S-4/5.5
Y132M-4/7.5
E
70
11
78
2.69
Y100L2-4/3
Y112M-4/4
Y132S-4/5.5
2900
A
190
80
80
51.72
Y250M-2/55
Y280S-2/75
Y315S-2/110
5
125
B
180
75
80
45.94
Y250M-2/55
Y280S-2/75
Y280M-2/90
C
170
70
80
40.49
Y225M-2/45
Y280S-2/75
Y280M-2/90
D
150
55
80
28.07
Y200L1-2/30
Y225M-2/45
Y250M-2/55
E
130
47
80
20.79
Y180M-2/22
Y200L2-2/37
Y225M-2/45
